2026 OpenClaw Gateway OpenAI-Compatible HTTP API in Practice: Enabling /v1/chat/completions, Auth, and Intranet/RAG Integration via SSH Port Forwarding — Reproducible Checklist + FAQ

1. Goals and scope

This checklist covers three things: ① expose /v1/chat/completions on the gateway in the same shape as the public OpenAI API; ② authenticate with a Bearer token and keep the listening surface minimal; ③ use SSH local port forwarding so a gateway that only listens on the data-center Mac's loopback is safely reachable from a laptop, with applications pointing their OpenAI base URL at the tunnel.

Out of scope here: public reverse proxies with automated TLS, multi-tenant billing, and exhaustive vector-database comparisons—those deserve separate architecture reviews.

2. Enabling OpenAI-compatible HTTP and /v1/chat/completions

In gateway configuration (or equivalent environment variables), turn on the OpenAI-compatible HTTP option and confirm the semantics match your compatibility layer:

• Path: POST /v1/chat/completions with a body containing model, messages, and optional stream.
• Response: non-streaming JSON; streaming uses text/event-stream with SSE-shaped lines (exact fields depend on your gateway version—follow its release notes).
• Model mapping: map OpenAI-style model names to real backends (cloud APIs, local Ollama, or hybrid routes); keep one alias table in config instead of scattering hard-coded names.

Production tip: default bind to 127.0.0.1 and expose only through localhost reverse proxy or SSH; if you must bind 0.0.0.0, add firewall rules, mTLS or proxy auth, and record the change in the runbook. For LaunchAgent coexistence when you split processes, see OpenClaw macOS dual LaunchAgent gateway + Mac agent in parallel — SSH headless checklist.

3. Authentication: Bearer tokens, rotation, and logs

The compatibility layer typically expects Authorization: Bearer <token>. Recommended practices:

• Inject OPENCLAW_GATEWAY_TOKEN (or the project's equivalent) into the dedicated user or LaunchAgent environment so CI and interactive debugging stay aligned with your secret store.
• On rotation, write the new secret first, then launchctl unload/load or restart the gateway—avoid a half-open state where clients already have the new token but the old process still validates the old one.
• Do not log full Bearer strings by default; log a short prefix plus request ID and correlate with upstream model logs when debugging.

4. SSH local port forwarding: bring the intranet gateway to your laptop

When the gateway only listens on the remote Mac's loopback, run on your dev machine (replace host, user, and ports):

ssh -N -L 18080:127.0.0.1:18789 user@remote-mac.example

Point your SDK base URL to http://127.0.0.1:18080/v1 (watch trailing-slash behavior for your client) and send the Bearer header on every call. For flaky tunnels, use ControlMaster to reuse connections or front the session with autossh, and document who may use SSH and how often keys rotate.

5. Intranet and RAG integration paths

A common split: retrieval and reranking stay on internal vector services; generation still goes through the gateway's chat compatibility layer. Watch for:

• Colocation: if embedding and chat share a host, 127.0.0.1 calls minimize latency; across hosts, use internal DNS and separate timeouts for retrieval vs model calls so one SLA does not hide inside the other.
• Credentials: keep vector API keys separate from gateway Bearer tokens; use different tokens for CI and manual debugging to simplify audits.
• Context limits: truncate or summarize before stuffing messages to avoid implicit 413s or surprise cloud bills.

6. Reproducible acceptance checklist

7. FAQ

Q: The SDK says "Invalid URL" but curl works.
A: Check for duplicated /v1 in the base URL, HTTPS vs HTTP mismatch with the tunnel, and system HTTP proxies intercepting traffic.

Q: Streaming responses stop halfway.
A: Align gateway and upstream timeouts; add ServerAliveInterval on SSH; confirm intermediaries are not buffering SSE.

Q: How do we share one gateway without leaking tokens?
A: Issue per-person or per-project sub-tokens if supported, or terminate OIDC at a reverse proxy; never commit Bearer secrets to public repositories.
